CPHI & PMEC China 2025   June 24-26,2025   Our booth number: N1D30   Welcome to our booth!     Chen Shanghai Tianfeng Pharmaceutical Equipment Co., Ltd. No.8 tianfeng road,Songjiang Zone,Shanghai,China Phone: 86-13524985109 WhatsApp: 86-13524985109 WeChat: 13524985109 Skype: 86-13524985109 Web: www.pilltabletpressmachine.com E-mail: chenyang@shtf.cn

Operating Instructions and Precautions for Tablet Press Machines I. Single-Punch Tablet Press A single-punch tablet press can compress various granular materials into round tablets, making it suitable for laboratory trials or small-scale production of medicinal tablets, sugar pills, calcium tablets, and irregularly shaped tablets. It is a compact bench-top electric (or manual) continuous compression machine equipped with one set of dies. The filling depth and tablet thickness can be adjusted, and different mold shapes can be selected based on formulation requirements. Understanding the Equipment 1. Main Structure The single-punch tablet press mainly consists of: - Dies (one set: upper punch, lower punch, die ring) - Adjusters (three: pressure, tablet weight, ejection) - Hopper - Feeder - Hand wheel (Refer to Figures 9-1 and 9-2.)   2. Working Principle - The lower punch enters the die bore from the bottom, sealing it. - The feeder fills the die bore with material. - The upper punch enters from the top and compresses the powder/granules into a tablet. - The upper punch retracts, while the lower punch rises to eject the tablet. - A scraper removes the tablet, completing one compression cycle. - The lower punch then resets for the next filling. (Refer to Figure 9-3.) 3. Compression Characteristics - Uses a single set of dies. - Only the upper punch moves during compression (unilateral pressure), leading to uneven force distribution, which may cause capping or lamination. - Output: **80–100 tablets/min**, suitable for R&D or small-scale production.   Operating the Equipment Usage Instructions a. Cleaning & Die Installation First, clean the machine and select the appropriate dies. (1) Die Installation ① Lower Punch Installation - Loosen the lower punch fixing screw. - Rotate the handwheel to raise the lower punch to its highest position. - Insert the lower punch (ensure the notch aligns with the screw) and tighten. ② Upper Punch Installation - Loosen the upper punch clamping nut. - Insert the upper punch fully and tighten using a wrench (grip the hexagonal base). ③ Die Installation - Loosen the die fixing screw. - Place the die horizontally into the die table (ensure the lower punch enters the die bore). - Tighten the screw. Avoid tilting to prevent damage. ④ Alignment Check - Rotate the handwheel to lower the upper punch into the die bore. - If collision/friction occurs, adjust the die table position by loosening its fixing screws (two). - Repeat until smooth insertion is achieved. (2) Ejection Adjustment - Rotate the handwheel to raise the lower punch fully. - Ensure the punch face is flush with the die table. If not: - Loosen the butterfly screw and gear plate. - Adjust the upper gear until aligned, then retighten. - Manually test-run the machine (~10 rotations) before trial compression. (3) Filling Depth (Tablet Weight) Adjustment - Loosen the butterfly screw and gear plate. - Rotate the lower gear left to raise the lower punch (reduces weight). - Secure the gear plate and screw after adjustment. (4) Pressure (Tablet Hardness) Adjustment - Loosen the connecting rod locknut. - Rotate the upper punch rod: - Left = Increased pressure (harder tablets). - Right = Decreased pressure (softer tablets). - Tighten the locknut and test-compress ~10 tablets. Check weight, hardness, and surface finish before full production. (5) Die Removal ① Upper Punch Removal - Loosen the clamping nut and pull out the punch (use pliers if tight; avoid damaging edges). ② Die Removal - Loosen the die fixing screw and lower punch screw. - Adjust the gear to raise the lower punch ~10 mm. - Gently rotate the handwheel to push the die out partially. Remove by hand. - If stuck, disassemble the die table. ③ Lower Punch Removal - Remove the fixing screw and raise the punch fully before extraction (use pliers if needed). ④ Post-Removal Adjustment - Retract the lower punch ~10 mm to prevent future collisions. - Reinstall the fixing screw. 2. Maintenance (1) Lubrication - Lubricate all moving parts (oil cups, holes, friction surfaces) before use. - Run idle to distribute oil. Replenish lubricant per shift (avoid overfilling). (2) Screw Inspection - Check and tighten screws before each shift and during operation, focusing on: - Upper punch nut, die screws, lower punch screw. - Connecting rod locknut, lift fork nuts , butterfly screw, die table screws (3) Die Cleaning - Clean dies after each use to ensure tablet appearance quality，And store it in lubricating oil.   II. Rotary Tablet Press A. Understanding the Equipment 1. Equipment Structure The main components of a rotary tablet press (Figure 9-4) include:   -Rotating turret (mounted on a central axis) - Upper and lower punches & dies - Compression rollers - Weight adjustment mechanism - Pressure adjustment mechanism - Hopper & feeder - Dust collector   The turret consists of three layers: - Upper layer: Holds multiple upper punches. - Middle layer: Contains die bores. - Lower layer: Houses corresponding lower punches.   During operation: - Punches rotate with the turret while moving vertically along fixed tracks. - When passing the compression rollers, the upper punch descends and the lower punch ascends, compressing granules in the die bore. - A fixed feeder continuously supplies material from the hopper into the dies. - Pressure adjustment: Achieved by raising/lowering the lower roller, altering the distance between punches. - Weight adjustment: Controlled via the lower punch track, modifying fill depth before compression.   Common models include 19-station (single-sided) and 35-station (dual-sided) presses. - Single-sided (e.g., ZP-19): One compression cycle per rotation (1 tablet per die). - Dual-sided (e.g., ZP-35): Two compression cycles per rotation (2 tablets per die).   2. Working Principle The compression cycle (Figure 9-5) involves:   1. Filling: - The lower punch passes under the feeder, filling the die bore. - The weight adjuster sets the fill height; excess material is scraped off. 2. Compression: - Punches meet at the rollers, minimizing the gap to form a tablet. 3. Ejection: - The lower punch rises to eject the tablet, which is guided into a container.   3. Compression Characteristics - Uniform feeding minimizes weight variation. - Bilateral pressure ensures even force distribution. - High output: 80,000–100,000 tablets/hour.   B. Operating the Equipment 1. Die Preparation - Remove dies from lubricant storage, clean with an oil-free cloth, and disinfect with alcohol. - Inspect for wear (especially punch tips) before installation. 2. Machine Assembly (1) Installing Dies - Loosen die fixing screws on the turret. - Place the die into the bore and gently tap it flush with the turret surface using a drift pin. - Tighten screws securely. (2) Installing Upper Punches - Remove the upper punch cover, parallel plate, and guide rail. - Insert each punch, ensuring smooth movement within the die. - Reinstall guide rails, plates, and covers after all punches are in place. (3) Installing Lower Punches - Open the side stainless steel cover and extend the lower punch rail. - Insert punches sequentially, then lock the rail and cover. - Rotate the turret manually to confirm smooth operation. (4) Installing the Feeder - Secure the crescent-shaped feeder onto the turret with screws. (5) Installing the Hopper - Place the hopper into the machine and set the material flow control to mid-position.   3. Machine Calibration - After assembly, manually rotate the turret to verify alignment. - Close the safety guard and conduct trial runs. - Adjust weight (via fill depth) and hardness (via thickness) as needed. - Monitor tablet quality (weight, hardness, appearance) during production.   4. Shutdown & Cleaning (1) Material Handling - Collect leftover material, label it, and submit to the intermediate storage. (2) Equipment Maintenance - Clean and lubricate the press. (3) Workspace Sanitization - Clean tools, containers, and surfaces. - QA inspection required before issuing a clearing certificate.     Shanghai Tianfeng Pharmaceutical Equipment Co., Ltd. No.8 tianfeng road,Songjiang Zone,Shanghai,China Phone: 86-13524985109 WhatsApp: 86-13524985109 WeChat: 13524985109 Skype: 86-13524985109 Web: www.pilltabletpressmachine.com E-mail: chenyang@shtf.cn

How to deal with tablet cracking issues? Here are 4 tips to help you solve it.   A tablet press is a machine that compresses dry granular or powdered materials into tablets using molds. Depending on the model, tablet presses can be categorized into single-punch tablet presses, basket tablet presses, rotary tablet presses, semi-high-speed rotary tablet presses, fully automatic high-speed tablet presses, and rotary encapsulated tablet presses. Different types of tablet presses have distinct functions and application ranges, but they commonly encounter the issue of tablet cracking. Why does this happen? The main reason is excessive fine powder in the granules, which traps air during compression. If the compression speed is too fast and the gap between the punch and die hole is small, the air cannot escape from the granules and gets trapped inside the tablet. Once the pressure is released, the air expands, causing the tablet to crack.     After consulting with industry experts, here are some methods to address tablet cracking under different circumstances:     1. Tablet cracking due to excessive pressure   When the granules are subjected to increased pressure, their expansion increases. If the adhesive's binding force cannot prevent this expansion, it results in cracking. The solution is to reduce the pressure.     2. Tablet cracking due to improper fit between the upper punch and die hole   Over time, wear and tear on the punches and dies cause misalignment, leading to uneven pressure distribution. This can result in excessive pressure on certain parts of the tablet, causing top splitting or deformation of the die ring. It is essential to replace the mold promptly.     3. Tablet cracking due to substandard granules   If the granules are too loose or contain too much fine powder, adjustments should be made to the adhesive concentration and quantity, and the granulation method should be improved. For granules that are too dry or lose too much crystallization water, controlling the moisture content during granulation according to different product specifications is crucial.     4. Tablet cracking due to improper adhesive selection   If the adhesive used during granulation is insufficient, resulting in poor adhesion and excessive fine powder, the dried granules may become too hard, making them difficult to disintegrate and causing surface pitting. Appropriate amounts of adhesive should be added; if there is too much fine powder, some can be sieved out. If the granules are too hard, they should be re-granulated and disintegrants added.     In recent years, with the rapid development of the pharmaceutical market, tablet press manufacturers have faced both opportunities and challenges. In increasingly fierce competition, manufacturers no longer focus solely on sales but strive to solve customers' problems and provide comprehensive services based on their needs. Consequently, the tablet press industry and companies are continuously accelerating their transformation and innovation.     However, some industry insiders point out that while some products have made significant breakthroughs, many lack technological content. For example, some products have similar structures, functions, and even identical production processes. To better adapt to industry development and meet user needs, China's tablet press industry must continue to advance towards higher speeds, greater productivity, better sealing, modularity, automation, and scale. By increasing innovation efforts, they can enhance their products and gain more market share and customer favor in the competitive tablet press market.   Shanghai Tianfeng Pharmaceutical Equipment Co., Ltd. No.8 tianfeng road,Songjiang Zone,Shanghai,China Phone: 86-13524985109 WhatsApp: 86-13524985109 WeChat: 13524985109 Skype: 86-13524985109 Web: www.pilltabletpressmachine.com E-mail: chenyang@shtf.cn

Visit Our Booth at Pharmtech & Ingredients 2024 Exhibition!   Our company will participate at the 26th International Exhibition of equipment, raw materials and ingredients for pharmaceutical production Pharmtech & Ingredients, that will be held on November 19 – 22,2024.   Visit our booth C9063 in the hall 8 of the pavilion 2, Crocus Expo, Moscow.   We will showcase: Pharmaceutical tablet press, powder mixer, pharmaceutical milling machinery, granulation machine, pharmaceutical packaging machinery and sugar coating machine. Our medical machinery is widely used in pharmacy, chemical, food, electronic and metallurgy industries. We specialize in development of any type of pharmaceutical tablet press, powder mixer, pharmaceutical milling machinery, granulation machine, pharmaceutical packaging machinery, Blister Packing Machine, Capsule Filling Machine and sugar coating machine.   Our specialists will be happy to make a presentation and answer your questions.   Use our PROMOCODE pha24eLEPF to get free e-ticket at the event website.     Get your free ticket https://pharmtech-expo.ru/ru/visit/visitor-registration-en/   See you at our booth!
