Place of Origin:
Shanghai, China
Brand Name:
Tianfeng
Certification:
CE/ISO
Model Number:
ZP45A ZP41F
Video
Video
| Model | ZP-45A | ZP-41F |
| Dies (sets) | 45 | 41 |
| Max. Pressure (KN) | 100 | 100 |
| Max. dia. of tablet (mm) | 13(special 16) | 16(special 22) |
| Max. Depth of fill (mm) | 15 | 15 |
| Max. Thickness of largest tablet (mm) | 6 | 6 |
| Rotational speed of revolving table(r/min) | 14-45 | 14-45 |
| Max. Capacity(pcs/h) | 243000 | 221400 |
| Diameter of rotary table (mm) | 460 | 460 |
| Diameter of middle bmould (mm) | 26 | 30 |
| Length of up and low punch pole (mm) | 22 | 22 |
| Length of the lower punch pole(mm) | 115 | 115 |
| Dimension (L*W*H)(mm) | 910x1220x1670 | 910x1220x1670 |
| Motor(KW) | 7.5kW 4L | 7.5kW 4L |
| Net Weight | 1950 | 1950 |
Installation and after sales service:
Installing and Commission: We will install and test the machine in best working condition before shipment. If customer requires our technician to adjusting the machine and train technician at arrival place, we will send technician there. All our expenses including round-trip air ticket to the nearest airport, local conveyance to your factory, Lodging & Boarding expenses shall be payable by you.
Warranty Period:
There is one year for fully machine guarantee. And in this year if the machine broken caused by Mechanical problem, all of the spare part is free. The service of the machine all though the machine’s life.
After Sales Service:
1. We have 24 hours hot line for technical support.
2. We get 18 hours internet line for technical support.
3. Video camera in workshop to help you adjust and solve machine problem in working situation.
Q1: What brand and models are available for the Pharmaceutical Pill Press?
A1: The Pharmaceutical Pill Press is offered under the brand name Tianfeng, with model numbers ZP45A and ZP41F available.
Q2: What certifications does this pill press have?
A2: The pill press is certified with CE and ISO, ensuring it meets international quality and safety standards.
Q3: Where is the Pharmaceutical Pill Press manufactured?
A3: The product is manufactured in Shanghai, China.
Q4: What is the minimum order quantity and payment options?
A4: The minimum order quantity is 1 unit. Payment can be made via T/T, Western Union, or L/C.
Q5: What is the typical delivery time and packaging method?
A5: Delivery time is typically 25 working days. The equipment is securely packed in a plywood export wooden case for safe transportation.
Q6: How many units can Tianfeng supply monthly, and how can I get pricing information?
A6: Tianfeng can supply up to 50 units per month. For pricing details, you are welcome to consult directly with the supplier.
